工業機器人是指由機械手(機械體)、控制器、伺服驅動系統和傳感裝置等組成，可由人操作、自動控制和重新編程，并能在三維空間完成各種操作的光機電一體化生產設備。特別適用于多品種、多批次的柔性制造系統。

Industrial robots refer to opto electromechanical integrated production equipment composed of robotic arms (mechanical bodies), controllers, servo drive systems, and sensing devices, which can be operated, automatically controlled, and reprogrammed by humans, and can complete various operations in three-dimensional space. Especially suitable for flexible manufacturing systems with multiple varieties and batches.

，工業機器人根據手臂的運動形式分為四種類型：

Firstly, industrial robots are divided into four types based on the movement of their arms:

1.矩形臂可以沿三個直角坐標移動；

1. The rectangular arm can move along three Cartesian coordinates;

2.圓柱坐標臂可以提升、旋轉和伸展；

2. The cylindrical coordinate arm can be lifted, rotated, and extended;

3.球坐標臂可以旋轉、俯仰和伸縮；

3. The spherical coordinate arm can rotate, pitch, and stretch;

4.鉸接臂有多個旋轉接頭。

4. The articulated arm has multiple swivel joints.

工業機器人根據執行機構運動的控制功能可分為點式和連續履帶式。

Industrial robots can be divided into point type and continuous track type based on the control function of the actuator movement.

1.點式僅控制執行機構從一點到另一點的精確定位，適用于機床裝卸、點焊和一般搬運、裝卸作業；

1. Point type only controls the precise positioning of the actuator from one point to another, suitable for machine tool loading and unloading, spot welding, and general handling and loading and unloading operations;

2.連續軌道式可控制執行機構按照給定的軌道運動，適用于連續焊接和噴漆作業。

2. The continuous track type controllable actuator moves according to the given track, suitable for continuous welding and painting operations.

3.工業機器人根據程序輸入方式可分為編程輸入型和教學輸入型：

3. Industrial robots can be divided into programming input type and teaching input type according to the program input method:

1.編程輸入類型為通過RS232串口或以太網將計算機上已編程的操作程序文件傳輸機器人控制柜。

1. The programming input type is to transfer the programmed operation program files on the computer to the robot control cabinet through RS232 serial port or Ethernet.

2.教學輸入類型有兩種教學方法：

There are two teaching methods for teaching input types:

一是操作者利用手動控制器(示教控制箱)將指令信號傳遞給驅動系統，使執行機構按照所需的動作順序和運動軌跡執行一次；

One is that the operator uses a manual controller (teaching control box) to transmit command signals to the driving system, so that the executing mechanism can execute once according to the required action sequence and motion trajectory;

另一種是操作者直接引導執行機構按照要求的動作順序和軌跡再次執行。在教學過程中，工作程序的信息自動存儲在程序存儲器中。當機器人自動工作時，控制系統從程序存儲器中檢測相應的信息，并將指令信號傳送給驅動機構，使執行機構能夠再現所示教的各種動作。教授輸入程序的工業機器人被稱為教學

Another approach is for the operator to directly guide the executing mechanism to execute again according to the required action sequence and trajectory. During the teaching process, the information of the work program is automatically stored in the program memory. When the robot operates automatically, the control system detects corresponding information from the program memory and transmits command signals to the driving mechanism, enabling the executing mechanism to reproduce various actions taught. Industrial robots that teach input programs are called teaching

具有觸覺、力覺或簡單的視覺的工業機器人，能在較為復雜的環境下工作；如具有識別功能或更進一步增加自適應、自學習功能，即成為智能型工業機器人。它能按照人給的“宏指令”自選或自編程序去適應環境，并自動完成更為復雜的工作。

Industrial robots with tactile, force, or simple vision, capable of working in complex environments; If it has recognition function or further adds adaptive and self-learning function, it becomes an intelligent industrial robot. It can adapt to the environment by selecting or programming according to the "macro instructions" given by humans, and automatically complete more complex tasks.
